CP32xx-0000 | “Economy” Panel PC
The Industrial PC with mounting arm and 3½-inch motherboard
| Variant | Processor | Available |
|---|---|---|
| CP32xx-0000 | Intel® Celeron®, 2 Cores (TC3: 50*) or Intel® Core™ i3, 2 Cores (TC3: 60*) or Intel® Core™ i5, 2 Cores (TC3: 70*) or Intel® Core™ i7, 4 Cores (TC3: 80*) | Yes, but not recommended for new projects |
Overview
| CP32xx-0000 | "Economy" Panel PC |
|---|---|
| Housing | Industrial PC with Control Panel for mounting arm installation |
| Rotatable and tiltable mounting arm adapter for Rittal and Rolec mounting arm systems with 48 mm tube from top | |
| Wiring area for up to 6 IP 65 connectors | |
| 1 slot for one 2½-inch hard disk or SSD and 1 slot for one CFast card | |
| Lithium battery of the system clock, changeable from outside | |
| Passive cooling through heat sink; internal fan for equal heat distribution to all the walls of the housing | |
| 20 cm free space required around the PC for air circulation | |
| Protection class IP 65 | |
| Operating temperature 0...45 °C | |
| Front panel | TFT display in seven sizes |
| - 12-inch display 800 x 600 | |
| - 15-inch display 1024 x 768 | |
| - 15.6-inch display 1366 x 768 | |
| - 18.5-inch display 1366 x 768 | |
| - 19-inch display 1280 x 1024 | |
| - 21.5-inch display 1920 x 1080 | |
| - 24-inch display 1920 x 1080 | |
| Multi-finger touch screen | |
| Features | Processor Intel® Celeron® B810 1.6 GHz, 2 cores (TC3: 50) |
| 3½-inch motherboard for 2nd and 3rd Generation Intel® Core™ i3, Core™ i5, Core™ i7 or Celeron® | |
| 1 Mini PCI slot free for cards installed ex factory | |
| 2 GB DDR3 RAM, expandable to 16 GB | |
| Graphic adapter integrated inside the Intel® processor, 1 DVI-D port occupied by the display in the front | |
| On-board dual Ethernet adapter with 2 x 10/100/1000BASE-T connector, one of these is led out in the wiring area | |
| On-board SATA RAID 1 controller, Intel® Rapid Storage Technology | |
| Hard disk, 2½-inch, 320 GB | |
| M23 built-in socket for power supply and 1 Harting push-pull Ethernet built-in socket 10/100/1000BASE-T in the wiring area | |
| 24 V DC power supply |
